4+1/8+1 Banknote Fitness Sorter

Reservation Now
FEATURESSPECIFICATIONS


1. Supports fitness sorting, denomination sorting, face/orientation sorting, version sorting, etc.

2. Fitness sorting: Mutilation, De-inked banknotes, Folded corners, Holes, Soil, Stains, Tape, Tears, Washed banknotes, Repairs.

3. Serial number reading and records.

4. Big display, friendly user interface.

5. Can extend to 8+1 pockets, 12+1 pockets, more efficient use.

6. Windows operation system, providing software interfaces to facilitate the subsequent developments at client side.

7. Access to note transport path, easy to clean and maintain.


DP-8510

DP-8600


Sensor

Dual CIS, MG, MT,   IR, UV, Mechanical Thickness

Free Count Speed

1200 notes/min

Value Count Speed

                        1000   notes/min

S/N Reading Speed

                        900   notes/min

Fitness sorting   Speed

                        900   notes/min

Stacker Capacity

600 notes*4

600 notes*8

Reject Pocket   Capacity

300 notes

Display

12.1" Touch   Display

Dimensions

715(W)X640(H)X380(D)   mm

1430(W)*640(H)*380(D)   mm

Weight

60.5 kg

100 kg

Power Supply

       AC 90-230 V, 50 Hz-60 Hz

Power Consumption

≤320 W

≤500 W

Interface

    DB9(RS232), USB, LAN, VGA

Operating System

Windows 10

Operating   Temperature

0°C~45°C

Storage Capacity

Up to 64 G
